IR up to 30M
Two-Way Audio
You can easily communicate in real-time through the app. Whether you’re speaking or listening, the audio feature allows for seamless, two-way communication, ensuring that both parties can hear and respond instantly.
Alarms
Arm and activate your alarm relays, deterrence lights, and sirens instantly through the Smart Guardian app. With just a few taps, you can ensure your property is fully secured, deterring potential intruders and triggering an immediate response.
Discover moreRemote Setup
With remote setup, you can complete your entire system configuration directly through the app, eliminating the need for connecting to a separate monitor or physical device. Our app gives you full control, ensuring a smooth, hassle-free setup experience without any extra equipment.
Learn more
Instant Notifications
Receive real-time alerts for various events, including alarm triggers, human and vehicle detections, movement, face recognition matches, hard disk errors, and video loss. Tailor your notifications to ensure you’re always updated on what’s happening.
Discover morePRODUCT SPECIFICATIONS
| OPERATIONAL | |
| IR Viewable Length | Up to 30m |
| Camera Title | Show/Hide |
| Day & Night | IR cut filter with auto switch (Day/Night/Auto/Image/Schedule) |
| Backlight Compensation | Off/On (5 Zones) |
| Wide Dynamic Range | WDR |
| Digital Noise Reduction | 3D DNR |
| Motion Detection | Off/On (8 Levels) |
| Privacy Masking | Off/On (4 Zones, Rectangle) |
| Gain Control | Auto |
| White Balance | Auto/Manual |
| Electronic Shutter Speed | 1/5 ~ 1/20000s |
| Image Setting | Flip/Corridor/Rotation |
| On-Board Storage | Micro SD slot, up to 256GB |
| Alarm | 1 input, 1 output |
| Audio | 1 input (RCA), 1 output (RCA) |
| Hardware Reset | Yes |
| Smart Features | Perimeter Intrusion Detection (PID), Line Crossing Detection (LCD), Stationary Object Detection (SOD), Human&Vehicle Detection (PD&VD), Face Detection (FD), Cross Counting (CC), Crowd Density Detection (CD), Queue Lenght Detection (QD), Heat Map (HM). |
| NETWORK | |
| Ethernet | RJ45(10/100BASE-T) |
| Video Compression Format | H.265/H.264 |
| Resolution | Mainstream@30fps 8MP(3840x2160), 5MP(2592x1944,3072x1728), 4MP(2592x1520), 3MP(2304x1296), 1080P(1920x1080), 960P(1280*960), 720P(1280x720) Substeam@30fps 720P(1280x720),VGA(640x480),QVGA(320x240) Mobilestream@30fps VGA(640x480), QVGA(320x240) |
| Max. Framerate | 25fps@8MP,5MP,4MP,3MP,2MP,960P,720P,VGA,QVGA 60Hz |
| Video Quality Adjustment | 8Kbps ~ 16Mbps |
| Bitrate Control Method | CBR/VBR |
| Streaming Capability | Triple-Stream(Main/Sub/Mobile) |
| IP | IPv4 |
| Protocol | TCP/IP,HTTP,DHCP,DNS,DDNS,RTP/RTSP, SMTP,NTP,UPnP,SNMP,HTTPS,FTP |
| Security | IP address filter; complicated password; Authenticated username and password |
| Streaming Method | Unicast/Multicast |
| Max. User Access | Max 7 (admin+user) |
| Application Programming Interface | ONVIF( Profile S/G/T) |
| Compatible Web Browsers | IE8,9,10,11, Chrome 44/lower, Firefox 51/lower, Safari 11/lower |
| GENERAL | |
| Operating Conditions | -30~ +55°C/less than ≤ 95% RH |
| Storage Conditions | -30~+60°C/less than ≤ 95% RH |
| Ingress Protection | IP67 |
| Input Voltage / Current | D12V/POE(IEEE802.3af) |
| Power Consumption (IR OFF) | 3W/4W |
| Power consumption (IR ON) | 5W/7W |
| Color/material | White/Metal |
| Dimensions (HXWXD) | Ø148.7x109mm |
| Weight | appr 960g |
| ENVIRONMENTAL | |
| Protection Rating | IK10 |
| LENS | |
| Focal Length (Zoom Ratio) | 2.7 ~ 13.5mm |
| Max. Aperture Ratio | F No. 1.83 (W) ~ 3.32(T) |
| Angular Field Of View | 33 ~111°, Vertical |
| Min. Object Distance | 0.8m(W) ~ 1m(T) |
| Lens Type | Motorized(Ø14) |
| VIDEO | |
| Imaging Device | 1/2.8" |
| Effective Pixels | 8MP 3840(H)×2160(V) |
| Scanning System | Progressive CMOS |
| Min. Illumination | Color 0.1lux @ F1.2(AGC ON) ; B/W 0 lux @ IR ON |
DOWNLOAD
| DATA SHEET | |
| EN_DATASHEET_D6Z2812IP8MP-AI_2024-10-01.pdf | Download |
| FR_DATASHEET_D6Z2812IP8MP-AI_2024-10-01.pdf | Download |
| FIRMWARE | |
| V21_Firmware_21.45.7.0_2021-02-05 | Download |
| V21_Firmware_21.45.7.0_2021-04-09 | Download |
| V21_Firmware_21.45.8.2.2_2022-07-01 | Download |
| V21_Firmware_21.45.8.2.3_2023-05-18 | Download |
| V21_Firmware_21.45.8.2.4.1_2024-09-26 | Download |
| V21_Firmware_21.45.8.2.4_2023-12-19 | Download |
