Two-Way Audio
You can easily communicate in real-time through the app. Whether you’re speaking or listening, the audio feature allows for seamless, two-way communication, ensuring that both parties can hear and respond instantly.
Alarms
Arm and activate your alarm relays, deterrence lights, and sirens instantly through the Smart Guardian app. With just a few taps, you can ensure your property is fully secured, deterring potential intruders and triggering an immediate response.
Discover moreRemote Setup
With remote setup, you can complete your entire system configuration directly through the app, eliminating the need for connecting to a separate monitor or physical device. Our app gives you full control, ensuring a smooth, hassle-free setup experience without any extra equipment.
Learn more
Instant Notifications
Receive real-time alerts for various events, including alarm triggers, human and vehicle detections, movement, face recognition matches, hard disk errors, and video loss. Tailor your notifications to ensure you’re always updated on what’s happening.
Discover morePRODUCT SPECIFICATIONS
| OPERATIONAL | |
| AI Features | PERIMETER INTRUSION DETECTION FACE DETECTION LINE CROSSING DETECTION STATIONARY OBJECT DETECTION* HUMAN & VEHICLE DETECTION CROWD DENSITY DETECTION* LICENSE PLATE DETECTION* RARE SOUND DETECTION* NOISE DETECTION* QUEUE LENGTH DETECTION* VIDEO TAMPERING* AI MAX CAPTURED QUANTITY 200,000 AI REGISTERED QUANTITY 10,000 *THESE AI FEATURES ONLY WORK WITH IP CAMERAS, OR ANALOG CAMERAS WITH 2MP OR MORE |
| Audio | 4 in / 1 out |
| NETWORK | |
| Web | IE10/11 Safari V12.1 above Firefox V.52 above Google chrome V.57 above Edge V.79 above |
| Ethernet | 1 RJ45 10/100 Base-T |
| GENERAL | |
| OSD Language | EN/FR/ES/DN/TC/IN/JP/KR |
| Dimension (WXHXD) | 300X227X53mm |
| Input Voltage / Current | DC12V/2A |
| Power Consumption (Excluding Hard Disk) | 4.7W |
| Operating Temperature/Humidity | 0°C~+40°C (32°F ~ 104°F) Humidity |
| HARD DRIVES | |
| Hard Drive PURPLE | NO PURPLE HDD , 1TB , 2TB , 4TB |
| INTERFACE | |
| P/W Reset | Press 10 seconds |
| VGA | 1 (1024*768, 1280*720, 1280*1024, 1440*900, 1920*1080) |
| HDMI | 1(1024*768, 1280*720, 1280*1024, 1440*900, 1920*1080 , 2560*1440, 3840*2160/EDID) |
| RECORDING BANDWIDTH | |
| Inputs | 12 Mbps-36Mbps IP Bandwidth default is 12Mbps, decrease one Analog channel can increase 6Mbps Total decoding performance 4K 30fps |
| Out | 48Mbps |
| Analog-Video-Input | 4CH Inputs |
| PERFORMANCE | |
| Installation Wizard | Yes |
| Compression | G.711a Video |
| Display Resolution | 8MP (15fps) 5MP (20fps) 4MP/1080P/720P/960H (30fps) IP |
| Speed | 8MP |
| Event | MD (Sensitivity Level 1~8) Videlo loss Beep, Email, Push notification to Mobile APP |
| Playback Function | Fast forward / backward (2x, 4x, 8x,16X) Slow forward (1/2x, 1/4x, 1/8x,1/16x) |
| Playback | 28fps 5MP |
| UI/MONITORING | |
| Local | UI5.0 |
| Mobile Viewer | SMART GUARDIAN |
| Push Notifications | Yes |
| BNC | 1 (704*576) |
| CONNECTIONS | |
| USB | USB2.0*1 (front) USB2.0*1+(rear) |
| E-SATA | 1 optional, not supported by default |
| HDD | The recorder can support up to 16TB |
| RS485 | 1 |
| Alarm Input/Out | 4 in /1 out |
| LIVE | |
| IP Video Input | 2ch,(only IP up to 6ch) |
| Composite Video Input | Up to 6ch (Analog video + IP video) |
