5MP Resolution
Two-Way Audio
You can easily communicate in real-time through the app. Whether you’re speaking or listening, the audio feature allows for seamless, two-way communication, ensuring that both parties can hear and respond instantly.
Alarms
Arm and activate your alarm relays, deterrence lights, and sirens instantly through the Smart Guardian app. With just a few taps, you can ensure your property is fully secured, deterring potential intruders and triggering an immediate response.
Discover moreRemote Setup
With remote setup, you can complete your entire system configuration directly through the app, eliminating the need for connecting to a separate monitor or physical device. Our app gives you full control, ensuring a smooth, hassle-free setup experience without any extra equipment.
Learn more
Instant Notifications
Receive real-time alerts for various events, including alarm triggers, human and vehicle detections, movement, face recognition matches, hard disk errors, and video loss. Tailor your notifications to ensure you’re always updated on what’s happening.
Discover morePRODUCT SPECIFICATIONS
| CAMERA | |
| Slow Shutter | Yes |
| Zoom | 33x optical |
| OPERATIONAL | |
| Day & Night | IR cut filter with auto switch (Day/Night/Auto/Image/Schedule) |
| Video Bit Rate | 8 kbps to 8192 kbps |
| Wide Dynamic Range | 120 dB |
| On-Board Storage | Micro SD card slot SD/SDHC/SDXC, up to 256 Go |
| Alarm | 1 input, 1 output |
| Audio | 1 Input, 1 Output |
| Hardware Reset | Yes |
| Smart Features | FD, PD&VD, PID, CC, SOD, HM, CD, QD, LPD, LDC |
| NETWORK | |
| Protocols | IPv4/IPv6, HTTP, HTTPS, FTP, SMTP, UPnP, SNMP, DNS, DDNS, NTP, RTSP, RTP, TCP/IP, UDP, DHCP, PPPoE, |
| Application Programming Interface | ONVIF( Profil S/G/T), HTTP API |
| Simultaneous | Live View Up to 15 channels |
| User/Host | 5 Users |
| Security | Password protection, complicated password, HTTPS encryption, IP address filter,control timeout settings |
| Client | VMS |
| Compatible Web Browsers | IE10/11, Safari V12.1 above, Firefox V.52 above, Google chrome V.57 above, Edge V.79 above |
| Main Stream | 25fps(2592x1944/2592x1520/2048x1536/2304x1296/ 1920x1080/ 1280x960/1280x720) 60 Hz |
| Sub-Stream | 25 fps (1280x720/640x480/320x240) 60 Hz |
| Video Compression | H.265+/H.265/H.264+/H.264 Sub-Stream |
| Audio Compression | G.711a/G.711u |
| Ethernet | 1 port Ethernet RJ45 10M/100M auto-adaptatif |
| GENERAL | |
| Operating Conditions | -30~+60°C/ less then ≤ 90% RH |
| Ingress Protection | IP66 |
| Input Voltage / Current | DC 12V/POE+, max. 25.6 W |
| Dimensions | Ø 206.4 mm × 351.8 mm |
| Weight | appro. 3700g |
| THERMAL MODULE | |
| Image Sensor | 1/2.7” |
| Max. Resolution | 5MP 2592(H)×1944(V) |
| OPTICAL MODULE | |
| Shutter Speed | 1/5 s to 1/20000 s |
| Supplement Light Range | Distance de l’IR jusqu’à 150 m |
| Supplement Light Type | IR |
| LENS | |
| Focal Length (Zoom Ratio) | 4.3 - 142mm |
| Max. Aperture Ratio | Max. F1.6 |
| Angular Field Of View | 55° à 2,3° (wide-tele) Vvertical |
| Focus | Auto/Manual |
| PTZ | |
| Movement Range(PAN) | 360° |
| Movement Range(TILT) | -10° to 90° (auto flip) |
| Pan Speed | 0.6° to 200°/s; preset speed |
| Tilt Speed | 0,6° to 90°/s preset speed |
| Presets | 255 |
| Patrol Scan | 1 Scan |
| Pattern Scan | 4 pattern |
| 3D Positioning | Yes |
| IMAGE | |
| Image Enhancement | BLC, HLC, 3D DNR |
| Image Settings | Saturation, brightness, contrast, sharpness, Hue and white balance adjustable by client software or web browser |
| Privacy Mask | Off/On (4 zones) |
| VIDEO | |
| Scanning System | Progressive CMOS |
| Min. Illumination | 0,003 Lux @ (F1.6, AGC ON), B/W |
| Third Stream | 25 fps (640x480/320x240) 60 Hz |
| H.264 TYPE | Baseline Profile/Main Profile/High Profile |
| H.265 TYPE | Main Profile |
| Region Of Interest (ROI) | NA |
| EVENT | |
| Basic Event | Motion detection, alarm input and output |
| Smart Tracking | auto-tracking |
| Alarm Linkage | Upload to FTP, send email, trigger alarm output, trigger recording |
DOWNLOAD
| DATA SHEET | |
| EN_DATASHEET_PTZ33XIP5MP-AI-N_2024-10-16.pdf | Download |
| FR_DATASHEET_PTZ33XIP5MP-AI-N_2024-10-16.pdf | Download |
| FIRMWARE | |
| V40_Firmware_40.45.8.2.4.1_2024-08-12 | Download |
| V40_Firmware_40.45.8.2.4_2023-12-01 | Download |
| USER MANUAL | |
| EN_USERMANUAL_PTZ_GSD_2024-08-09.pdf | Download |
| FR_USERMANUAL_PTZ_GSD_2024-08-09.pdf | Download |
