True WDR
Two-Way Audio
You can easily communicate in real-time through the app. Whether you’re speaking or listening, the audio feature allows for seamless, two-way communication, ensuring that both parties can hear and respond instantly.
Alarms
Arm and activate your alarm relays, deterrence lights, and sirens instantly through the Smart Guardian app. With just a few taps, you can ensure your property is fully secured, deterring potential intruders and triggering an immediate response.
Discover moreRemote Setup
With remote setup, you can complete your entire system configuration directly through the app, eliminating the need for connecting to a separate monitor or physical device. Our app gives you full control, ensuring a smooth, hassle-free setup experience without any extra equipment.
Learn more
Instant Notifications
Receive real-time alerts for various events, including alarm triggers, human and vehicle detections, movement, face recognition matches, hard disk errors, and video loss. Tailor your notifications to ensure you’re always updated on what’s happening.
Discover morePRODUCT SPECIFICATIONS
| CAMERA | |
| Slow Shutter | Yes |
| Zoom | 4x optical |
| OPERATIONAL | |
| Day & Night | IR cut filter with auto switch (Color/Day/Night/Auto/Image/Schedule) |
| Video Bit Rate | 8 kbps to 8192 kbps |
| Wide Dynamic Range | 120 dB |
| Smart Features | Perimeter Intrusion Detection (PID), Line Crossing Detection (LCD), Stationary Object Detection (SOD), Human&Vehicle Detection (PD&VD), Face Detection (FD), Cross Counting (CC), Crowd Density Detection (CD), Queue Lenght Detection (QD), Heat Map (HM) |
| On-Board Storage | Micro SD card slot SD/SDHC/SDXC, up to 256 Go |
| Alarm | N/A |
| Audio | Built-in microphone & speaker |
| Hardware Reset | Yes |
| NETWORK | |
| Main Stream | 50fps (2560x1440/2304x1296/1920x1080/1280x720) 60Hz |
| Sub-Stream | 50fps (1280x720/640x480/320x240) 60Hz |
| Video Compression | H.265+/H.265/H.264+/H.264 Substream |
| Audio Compression | G.711a/G.711u |
| Protocols | IPv4/IPv6, HTTP, HTTPS, FTP, SMTP, UPnP, SNMP, DNS, DDNS, NTP, RTSP, TCP/IP, UDP, DHCP, PPPoE, |
| Application Programming Interface | ONVIF( Profil S/G/T), HTTP API |
| Simultaneous | Live View Up to 15 channels |
| User/Host | 5 Users |
| Security | Password protection, complex password, HTTPS encryption, IP address filter, timeout control settings. |
| Client | VMS |
| Compatible Web Browsers | IE10/11, Chrome V.57/above, Firefox V.52/above Safari V.12.1/above, Edge V.79/above |
| Ethernet | 1 RJ45 10M/100M self-adaptive Ethernet port |
| GENERAL | |
| Ingress Protection | IP66 |
| Color/material | White/Metal |
| Operating Conditions | -30~+60°C/ less then ≤ 90% RH |
| Input Voltage / Current | DC 12V/POE - MAX 13W |
| Dimensions | Ø 166.75 mm × 238 mm |
| Weight | appro. 920g |
| THERMAL MODULE | |
| Image Sensor | 1/1.8” |
| Max. Resolution | 4MP 2560(H)x1440(V) |
| OPTICAL MODULE | |
| Shutter Speed | 1/5 s to 1/20000 s |
| Supplement Light Range | up to 20 m |
| Supplement Light Type | IR & warm light |
| ENVIRONMENTAL | |
| Protection Rating | IK10 |
| LENS | |
| Focal Length (Zoom Ratio) | 2.8 - 12 mm |
| Max. Aperture Ratio | Max. F1.3 |
| Angular Field Of View | 114.6° to 48.3° (wide-tele) Vertical |
| Focus | Auto/Manual |
| PTZ | |
| Movement Range(PAN) | 350° |
| Movement Range(TILT) | 0° to 80° |
| Pan Speed | configurable from 0.6° to 54°/s |
| Tilt Speed | configurable from 0.6° to 52°/s |
| Presets | 255 (Preset calls have a limit of 20,000 times) |
| IMAGE | |
| Image Enhancement | BLC, HLC, 3D DNR |
| Image Settings | Saturation, brightness, contrast, sharpness, Hue and white balance adjustable by client software or web browser |
| Privacy Mask | Off/On (4 zones) |
| VIDEO | |
| Scanning System | Progressive CMOS |
| Min. Illumination | 0.001 Lux @ (F1.3, AGC ON), B/W |
| Third Stream | 50fps (340x480/320x240) 60Hz |
| H.264 TYPE | Baseline Profile/Main Profile/High Profile |
| H.265 TYPE | Main Profile |
| Region Of Interest (ROI) | N/A |
| EVENT | |
| Basic Event | Motion detection |
| Smart Tracking | N/A |
