UP TO 30 WATTS PER PORT
Two-Way Audio
You can easily communicate in real-time through the app. Whether you’re speaking or listening, the audio feature allows for seamless, two-way communication, ensuring that both parties can hear and respond instantly.
Alarms
Arm and activate your alarm relays, deterrence lights, and sirens instantly through the Smart Guardian app. With just a few taps, you can ensure your property is fully secured, deterring potential intruders and triggering an immediate response.
Discover moreRemote Setup
With remote setup, you can complete your entire system configuration directly through the app, eliminating the need for connecting to a separate monitor or physical device. Our app gives you full control, ensuring a smooth, hassle-free setup experience without any extra equipment.
Learn more
Instant Notifications
Receive real-time alerts for various events, including alarm triggers, human and vehicle detections, movement, face recognition matches, hard disk errors, and video loss. Tailor your notifications to ensure you’re always updated on what’s happening.
Discover morePRODUCT SPECIFICATIONS
| GENERAL | |
| Power Consumption | The device <5W | POE power supply <120W |
| Working Temperature | -10°C~ 55°C |
| Storage Temperature | -40°C~ 85°C |
| Humidity (Non-Congeal) | 0~95% |
| Dimensions | 202mmx140mmx44mm |
| Weight | 1.2kg |
| Mean Time Between Failures (MTBF) | >50000h |
| POWER RANGE | |
| Voltage Range | AC 100-240V |
| NETWORK PORT PARAMETER | |
| Network Ports | 10/100/1000Mbps Ethernet port Adaptive control 2-Port 10/100/1000Mbps RJ45 interface for uplink |
| Transmission Distance | 0~100m |
| Transmission Media | Cat5e/6 standard UTP cable |
| POE Agreement | IEEE802.3 af/at standards |
| POE Power Supply Mode | End-Span Method |
| POE Power Supply Wattage | Each port≤30W | Whole device<120W |
| NETWORK SWITCH SPECIFICATION | |
| Network Standard | IEEE802.3 10BASE-T IEEE802.3u 100BASE-TX IEEE802.3ab 1000BASE-T |
| Swap Mode | Store-and-forward |
| Switch Capacity | 20Gbps |
| Mac Address List | 8K |
| STATUS INDICATOR | |
| Power Indicator Light | One power light (green) |
| POE Indicator | 1~8 PoE indicator light (yellow) |
| Network Port LED | 1~10 port ( green light on RJ45 jack) Keeps on when normally connected, Blinking when transceiver data |
| PROTECTION LEVEL | |
| Surge Immunity | IEC61000-4-5 |
| Electrostatic Protection | level 3 1a Air discharge |
| COLOR | |
| Color | BLACK |
