5MP Resolution
Two-Way Audio
You can easily communicate in real-time through the app. Whether you’re speaking or listening, the audio feature allows for seamless, two-way communication, ensuring that both parties can hear and respond instantly.
Alarms
Arm and activate your alarm relays, deterrence lights, and sirens instantly through the Smart Guardian app. With just a few taps, you can ensure your property is fully secured, deterring potential intruders and triggering an immediate response.
Discover moreRemote Setup
With remote setup, you can complete your entire system configuration directly through the app, eliminating the need for connecting to a separate monitor or physical device. Our app gives you full control, ensuring a smooth, hassle-free setup experience without any extra equipment.
Learn more
Instant Notifications
Receive real-time alerts for various events, including alarm triggers, human and vehicle detections, movement, face recognition matches, hard disk errors, and video loss. Tailor your notifications to ensure you’re always updated on what’s happening.
Discover morePRODUCT SPECIFICATIONS
| OPERATIONAL | |
| Day & Night | IR cut filter with auto switch (Day/Night/Auto/Schedule) |
| AI Features | Intrusion, Region Entrance, Region Exiting, Line Crossing, Pedestrian & Vehicle, Object Detection, Crossing Counting, Crowd Density, Queue Length, Heat MAP, Rare Sound, Face Detection Thermal |
| NETWORK | |
| Main Stream | 50Hz@25fps; 5MP(2592x1944),4MP(2592x1520),3MP(2304x1296), 1080P(1920x1080), 960P(1280*960),720P(1280x720) 60Hz@30fps; 5MP(2592x1944),4MP(2592x1520),3MP(2304x1296), 1080P(1920x1080), 960P(1280*960),720P(1280x720) Thermal |
| Sub-Stream | 50Hz@25fps; 720P(1280x720),VGA(640x480),QVGA(320x240) 60Hz@30fps; 720P(1280x720),VGA(640x480),QVGA(320x240) Thermal |
| Mobile Stream | 50Hz@25fps; VGA(640x480),QVGA(320x240) 60Hz@30fps; VGA(640x480),QVGA9320x240) |
| Video Compression | H.265/H.265+/H.264/H.264+MJPEG |
| Audio Compression | G.711u/G.711a |
| Protocols | TCP/IP,HTTP,DHCP,DNS,DDNS,RTPRTSP,SMTP,NTP,UPnP,SNMP,HTTPS,FTP |
| User/Host Level | Administrator, User |
| Security Measures | User authentication (ID and PW), HTTPS encryption, IP address filtering |
| GENERAL | |
| Menu Language | English, Russian, German, Italian, French, Portuguese, Spanish, Turkish, Japanese |
| Power | 12 VDC ± 20%, PoE (802.3af) |
| Power Consumption | Max.10.4W |
| Working Temperature/Humidity | -35 °C to 60 °C (-31 °F to 140 °F) ; Humidity |
| Protection Level | IP67 |
| Dimensions | ∅108mm*314.6mm(∅4.25”*12.39”) |
| Weight | Approx. 1.25kg(2.76lb) |
| Environment | RoHS2.0 |
| THERMAL MODULE | |
| Image Sensor | Vanadium Oxide Uncooled Focal Plane Arrays , 1/2.7” Progressive Scan CMOS |
| Max. Resolution | 256×192 |
| Pixel Interval | 12μm |
| Response Waveband | 8-14μm |
| NETD (Noise Equivalent Temperature Difference) | ≤40mk@25°C F#1.0, 25Hz |
| Lens (Focal Length) | 3.2mm , 3.6mm |
| IFOV | 3.75 mrad |
| Field Of View | 56°x42° , 81°, Vertical |
| Min. Focusing Distance | 0.3m |
| VCA Distance Human | 18.6m (61ft) |
| VCA Distance Vehicle | 49m (161ft) |
| Heat Detection Distance | 20m(66ft) |
| Aperture | F1.1 |
| OPTICAL MODULE | |
| Max. Image Resolution | 2592*1944 |
| Shutter Speed | 1/5 s to 1/100,000 s |
| WDR | 120 dB |
| Bi-Spectrum Image Fusion | Fusion view of thermal view and overlaid details of the optical channel |
| Supplement Light Type | IR and Warm Light |
| Supplement Light Range | Up to 30 m (IR) / 15m (Warm light) |
| IR Wavelength | 850mm |
| Smart Supplement Light | Yes |
| Warning Light | 1 Red & 1Blue flashing light |
| SMART FUNCTION | |
| Temperature Measurement | Gobal, 12 points, 12 areas, and 12 line. |
| Temperature Range | -20 °C to + 150 °C (-4 °F to + 302°F) |
| Temperature Accuracy | ± 8 °C (± 14.4 °F) |
| Fire Detection | Yes |
| INTEGRATION | |
| Alarm Input | 1-ch inputs |
| Alarm Output | 1-ch outputs |
| Alarm Action | SD recording/Alarm output/smart capture/FTP upload/ email linkage/ audio alarm/Red & Blue flashing light |
| Audio Input | 1-ch |
| Audio Output | 1-ch outputs/ 1 Built-in speaker |
| Reset | Yes |
| Communication Interface | 1, RJ45 10M/100M self-adaptive Ethernet interface. |
| SD Memory Card | Built-in micro SD card slot (up to 256GB) |
| Analog Video Output(BNC) | NA |
| Web Browser | IE10/11, Safari V12.1 above, Firefox V.52 above, Google chrome V.57 above, Edge V.79 above |
| VIDEO | |
| Min. Illumination | 0.003 Lux @(F1.6,AGC ON), B/W |
